What is the Fuse Box Diagram for the Hyundai Santa Cruz Pickup?

Model: Hyundai Santa Cruz MK 1 - Years 2021-2026
Part: Fuse box

In this video, you can see where the fuse boxes are located in the Hyundai Santa Cruz pickup and what their respective diagrams are, useful in case you need to check the fuses of a malfunctioning device. The first box is inside the cabin, behind the small door located in the lower left area of the dashboard on the driver's side. The second box is located in the engine compartment, protected by the black plastic cover next to the battery. Make sure to replace any blown fuses with replacements of the same amperage.
